Oil Free Scroll Compressor Manufacturer & Supplier in China
We hope to let you know our advantages and win-win cooperation in the least time.
- Oil free, to avoid oil leakage and oil in compressed gas.
- Continuous scroll compression, no useless work, high efficiency, low energy consumption
- There are few parts, which greatly reduces the possibility of parts replacement, and has high durability
- When working, the moving and static scrolls do not touch, the vibration is small, and the noise is low
- Avoid regular cleaning of oil discharge and environmental protection treatment of waste oil, and achieve zero emissions.
- 100% oil-free: can be used in any industry, especially suitable for users with high oil content requirements in compressed air
- Quiet operation: The operating noise of the scroll air compressor is extremely low, and the working environment is healthier.
- Easy installation: It occupies a small area and can be installed near the air point, thereby reducing the installation of a compressed air pipe network and effectively reducing the cost of the pipe network installation.
- Simple maintenance: No need to replace or add lubricating oil, only a small amount of consumables need to be replaced regularly, and the maintenance cost is low.
- Zero discharge: discharge only condensate water, no discharge of harmful substances, in line with sustainable development goals
Compression principle
The compression process of the oil-free scroll is realized by the rotating motion of the fixed scroll and the movable scroll. The air enters from the outside of the air end, and the moving scroll closes the air inlet after the air is sucked in. As the orbiting scroll rotates, the air is continuously compressed, and the compressed oil-free air is discharged from the center of the fixed scroll. This process is continuously repeated to ensure that the discharged compressed air is continuous without fluctuations
| Model | Volume flow (L/min) | Rated Power(KW) | Working Pressure (MPa) | Noise (dB(A)) | Dimensions (mm) | Outlet Diameter | Weight (kg) |
| SLT-02A-8 | 240 | 2.2 | 0.8 | 57±2 | 550*600*700 | 1/2” | 220 |
| SLT-02A-10 | 210 | 2.2 | 1 | 57±2 | 550*600*700 | 1/2” | 220 |
| SLT-02CA-8 | 240 | 2.2 | 0.8 | 57±2 | 1290*600*1270 | 1/2” | 240 |
| SLT-02CA-10 | 210 | 2.2 | 1 | 57±2 | 1290*600*1270 | 1/2” | 240 |
| SLT-02SAT-8 | 240 | 2.2 | 0.8 | 57±2 | 665*935*1240 | 1/2” | 260 |
| SLT-02SAT-10 | 210 | 2.2 | 1 | 57±2 | 1290*600*1270 | 1/2” | 260 |
| SLT-04A-8 | 420 | 3.7 | 0.8 | 57±2 | 550*600*700 | 1/2” | 300 |
| SLT-04A-10 | 350 | 3.7 | 1 | 57±2 | 550*600*700 | 1/2” | 300 |
| SLT-04CA-8 | 420 | 3.7 | 0.8 | 57±2 | 1290*600*1270 | 1/2” | 330 |
| SLT-04CA-10 | 350 | 3.7 | 1 | 57±2 | 1290*600*1270 | 1/2” | 330 |
| SLT-04SAT-8 | 420 | 3.7 | 0.8 | 57±2 | 665*935*1240 | 1/2” | 350 |
| SLT-04SAT-10 | 350 | 3.7 | 1 | 57±2 | 1290*600*1270 | 1/2” | 350 |
| SLT-05A-8 | 620 | 5.5 | 0.8 | 57±2 | 750*800*900 | 1/2” | 360 |
| SLT-05CA-8 | 620 | 5.5 | 0.8 | 57±2 | 1490*800*1470 | 1/2” | 390 |
| SLT-05SAT-8 | 620 | 5.5 | 0.8 | 57±2 | 665*935*1240 | 1/2” | 410 |
| SLT-07A-8 | 830 | 7.5 | 0.8 | 58±2 | 1225*760*1350 | 3/4” | 400 |
| SLR-07A-10 | 700 | 7.5 | 1 | 58±2 | 1225*760*1350 | 3/4” | 400 |
| SLT-11A-8 | 1250 | 11 | 0.8 | 59±2 | 1225*760*1350 | 3/4” | 440 |
| SLT-11AI-8 | 1050 | 11 | 0.8 | 59±2 | 1225*750*1795 | 3/4” | 520 |
| SLT-11AI-10 | 1050 | 11 | 1 | 59±2 | 1225*750*1795 | 3/4” | 520 |
| SLT-15A-8 | 1670 | 15 | 0.8 | 62±2 | 1540*1275*1370 | 1” | 650 |
| SLT-15A-10 | 1380 | 15 | 1 | 62±2 | 1540*1275*1370 | 1” | 650 |
| SLT-16A-8 | 1860 | 16.5 | 0.8 | 62±2 | 1225*750*1795 | 1” | 580 |
| SLT-18A-8 | 2080 | 18.5 | 0.8 | 65±2 | 1540*1270*1815 | 1” | 800 |
| SLT-18A-10 | 1725 | 18.5 | 1 | 65±2 | 1540*1270*1815 | 1” | 800 |
| SLT-22A-8 | 2480 | 22 | 0.8 | 65±2 | 1540*1275*1370 | 1” | 730 |
| SLT-22AI-8 | 2070 | 22 | 0.8 | 66±2 | 1540*1275*1815 | 1” | 900 |
| SLT-22A-10 | 2070 | 22 | 1 | 66±2 | 1540*1275*1815 | 1” | 900 |
